Pressure seal for ribbed pipes
Pressure seal for ribbed pipe.
|
Borehole / cast-in pipe |
Fitting |
Code |
|
60mm |
Max. 22mm |
HDA 60/2/... |
|
70mm |
Max. 25mm |
HDA 70/2/... |
|
80mm |
Max. 45mm |
HDA 80/2/... |
|
100mm |
Max. 66mm |
HDA 100/2/... |
|
125mm |
Max. 87mm |
HDA 125/2/... |
|
150mm |
Max. 112mm |
HDA 150/2/... |
|
200mm |
Max. 162mm |
HDA 200/2/... |
|
250mm |
Max. 212mm |
HDA 250/2/... |
|
300mm |
Max. 260mm |
HDA 300/2/... |
|
350mm |
Max. 300mm |
HDA 350/2/... |
|
400mm |
Max. 350mm |
HDA 400/2/... |
|
450mm |
Max. 400mm |
HDA 450/2/... |
|
500mm |
Max. 450mm |
HDA 500/2/... |
*Other sizes available on request.
